Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS SRT
Model :3000VA
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :USB
Expansion Slots
Expansion Slots :1 (total) / 1 (free) x SmartSlot
Interface Provided
Interfaces :1 x serial – RJ-45, 1 x management (USB) – 4 pin USB Type A, 1 x EPO (emergency power off)
Software
Type :Drivers & Utilities
Power Device
Form Factor :External
UPS Technology :On-line
Voltage Provided :AC 208/230 volt
Frequency Provided :50/60 hertz
UPS Output Waveform :Sinewave
Power Provided :2700 watt
Power Capacity (VA) :3000 volt ampere per kilogram 3000VA
Voltage Required :AC 208/230 volt
Input Voltage Range :AC 160 – 275 V
Frequency Required :40 – 70 hertz
Input Connector Qty :1
Output Connector Type :Power IEC 60320 C13, Power IEC 60320 C19
Output Connector Qty :8
Surge Suppression :Yes
Surge Energy Rating :340 joules
Power Device Features :Audible alarm, Eco-Mode, LCD display, Internal bypass
Power Output Connectors Details
Power Output Connectors Details :6 x power IEC 60320 C13, 2 x power IEC 60320 C19
Battery
Run Time (Up To) :3.8 minute (time unit)
Load Type :At full load
Recharge Time :3 Hours
Lead Acid Battery Features :Maintenance free, Sealed, Leak-proof
Run Time Details
Run Time (Up To) :11.4 min at half load, 3.8 min at full load
UPS
Battery Technology :Lead acid
Miscellaneous
Color :Black
Color Category :Black
Included Accessories :Vertical stand
Compliant Standards :IEC 62040-2, IP20, CSA C22.2 No. 107.3, EAC, VDE, RoHS, FCC Part 15 A, UL 1778, RCM, EN 62040-2
Environmental Standards
ENERGY STAR :Yes
Dimensions & Weight
Width :3.3 inch
Depth :25 inch
Height :17 inch
Weight :69 lbs
Dimensions & Weight (Shipping)
Shipping Width :23.6 inch
Shipping Depth :34.3 inch
Shipping Height :9.7 inch
Shipping Weight :81 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95% (non-condensing)
Sound Emission :55 dBA
